Technical¶

Configuration explanations¶

Here is an explanation of all the components that can be configured in lime-admin

In version 2 of the newsletter integration we introduced support for different types of send-outs, e.g newsletters and product information. This can be done by mapping consent types in Lime CRM to publications in Lime Marketing. Consenttype mapping is used to tell lime-newsletter which consent type to use for what publication(s).

You can for example map the Product info consent type in Lime CRM to the publications Lime CRM customer info, Lime Go customer info and Lime Easy customer info:

newsletter-consenttypemapping

You need the ids of the consent type and the publications in question. The id of the publication can be found by pressing the i-symbol in the list of publications in Lime Marketing.

If you don't have consent type and consent tables in your database leave the consenttypemapping empty

Import fields¶

You can specify which properties from the Marketing Activity participants you want to be available in Lime-Marketing using the Import fields under the Required limetypes -> Participant limetype settings in the configuration in Lime Admin.

This can later be used when replacing merge fields in your emails. For example if you want to use the firstname property of a person in an email, first you add person.firstname in your Import fields. You can later map the property to an existing recipient property in Lime Marketing or create a new one. This is done in Administration > Integrations > "Your integration name" > Newsletter settings. In the picture below you can see how the mapping looks like and where you can create a new recipient property. The property can later be used in your email, for example "Hello $$recipient.Firstname$$", if you have mapped the property to the "Firstname" recipient property.

recipient-property

Id and email are mandatory for the integration to work. The id is later used to connect a recipient to a 'person' in Lime CRM.

All importfields must start from the participant limetype but can be any related properties found on the card. Note that only one-to-one (like participant toperson) or *many-to-one* (likepersontocompany`) relations are supported.

Example using person:

newsletter-importfields

Example using company:

newsletter-importfields-company

All importfields must start from the participant card but can be any related properties found on the card. Note that only one-to-one (like participant to person) or many-to-one (like person to company) relations are supported. Date, time and set properties are not supported.

The importfields are validated on the server and will display an error if any non-existing tables or fields are being used. Read access to any fields used are also validated.

Campaign types and campaign statuses¶

Campaigntypes and campaignstatus are used to filter which marketing activities that should be selectable in Lime-Marketing. You can change which types and statuses of campaign you want to see in Newsletter under Required limetypes -> Campaign limetype settings:

newsletter-campaign-type-status

If you leave these empty all marketing activities will be selectable in Lime-Marketing

Note that when using lime-newsletter and addon-lime-event the same filter for the campaigns must be used in both configs.

Opt-in settings¶

You can configure the integration to automatically create new limeobjects when someone submits the opt-in form of one or more chosen publications. The feature requires that the limetype has an email field. You must also make sure that all the required fields for the limeobject are present in the Field mappings section. The same applies for the opt-in form in Lime Marketing, all the required fields must be present and set to required in the form.

¶

In the section Field mappings the first field is the name of the lime property and the second field is the recipient property name in Lime Marketing. The recipient property name in Lime Marketing can be found in Administration -> Email recipient properties.

optin_property_name

As mentioned you need to make sure that all required properties on the limetype have required form fields on the opt-in form in Lime Marketing. The integration cant create the lime type if not all required fields have data. So make sure that all the required fields has its corresponding field in Lime Marketing and that they are marked as required. Open this editor by clicking on the "Subscription form" link on the publication settings page.

optin_field_name

Settings¶

You can control if the feature is active with the Enabled field.

Create duplicates controls if you should be able to create a new object if there is already an object with the same email address.

Publications contain the ids of all publications that should be able to create new objects. Leave this empty if you want opt-ins from all publications to create objects.

Limetype settings¶

newsletter-optinsettings

Limetype to create is the limetype you want to create, for example person or lead.

Email property for limetype is the email field on the selected limetype. Note that the field must be present in the Field mappings.

Field mappings is a list of mapped properties between Lime properties and Marketing recipient properties. Map the lime property and the corresponding Marketing opt-in form field name.
It is not possible to map to a property on a relation field. Simple field types works. I.e. the following types: string, text, link, integer, decimal, date, phone, mobilephone.

Opt-in eventhandler¶

All opt-in events are always published to the event handler on the lime.lime_newsletter exchange and newsletter.opt_in routing key. The event handler payload will contain:

The publication name and id found in the webhook payload
The email address of the recipient who opted in
The full webhook payload from lime-marketing

If a person who already exists in Lime CRM opts in the person record id will be added to the payload as well.

Example opt-in event payload:¶

{
  "person": {"Id": 1001},
  "publication": {
      "id": 123,
      "name": "Nyhetsbrev",
  },
  "email": "[email protected]",
  "original_event": {
    "Publication": {
      "Id": 123,
      "Name": "Nyhetsbrev"
    },
    "MailRecipient": {
      "Id": 17,
      "Email": "[email protected]",
      "Properties": {}
    },
    "ResponseWasUpdated": false,
    "Form": {
      "Id": 220,
      "Name": "Opt-in: Nyhetsbrev",
      "FormType": "SUBSCRIPTION",
      "FormResponseId": 21,
      "FormFieldValues": [
        {
          "Id": 44,
          "Name": "Email",
          "FormFieldPropertyType": "EMAIL",
          "ControlType": "TEXT",
          "Value": "[email protected]",
          "Values": [],
          "FieldLabel": "Email",
          "ValueOptions": [],
          "FormFieldDataType": "Email"
        }
      ],
      "FormFields": [
        {
        "Id": 80,
        "Name": "Email",
        "FormFieldPropertyType": "EMAIL",
        "ControlType": "TEXT",
        "FieldLabel": "Email",
        "FormFieldDataType": "Email"
        }
      ]
    },
    "FormResponseType": "PublicationOptIn",
    "EventRaisedUtcTimeStamp": "2025-06-08T11:55:46.372831"
  }
}

Link clicks¶

Link click settings are used for enabling the tracking of link clicks in Lime.

These settings are found under Optional limetypes in the left hand menu.

The Linclick enabled checkbox controls whether linkclicks should be created or not.

newsletter-linkclick-enabled

Configure the limetype by selecting the linkclick limetype, the other fields will automatically be mapped if they exist in the database:

newsletter-linkclick

Set the value for person to the object you are sending your newsletter to (e.g. company or person).

See required structure for instructions on how to set up the link click card.

Mail openings¶

Email opening settings are used for enabling the tracking of email openings in Lime.

These settings are found under Optional limetypes in the left hand menu.

The Email opening enabled checkbox controls whether emailopenings should be created or not.

newsletter-emailopening-enabled

Configure the limetype by selecting the emailopening limetype, the other fields will automatically be mapped if they exist in the database:

newsletter-emailopening

Set the value for person to the object you are sending your newsletter to (e.g. company or person).

See required structure for instructions on how to set up the emailopening card.

Get Recipients¶

With the getrecipientsenabled in your config you can control whether you want to be able to fetch mailing recipients from a mailing into Lime Marketing. If the property is not included in the config the value is by default set to true. Contact the Marketing Tech team for more information.

Object content¶

The Object content config is a list of lime-queries.

Set a unique queryname for each item.

Paste your lime-query in the code-editor.

newsletter-objectcontent

You can use all features of lime-query like nested objects and setting aliases for your fields. But it's important to set the exp value of the filter to "{0}" since this is what is inserted from the search input in Lime Marketing. Since Vue can not handle properties stating with '_' or '$' it is recommended to create an alias for any system properties like '_id' or '_descriptive'. If you forget to do this, the illegal characters will automatically be cleaned by Lime Marketing before you insert the data.

Not sent due to...¶

Enable the 'Not sent status' functionality by checking 'Not sent status' enabled on the start page for each configuration instance. This will allow you to see why some recipients did not recieve the mail.

not_sent_due_to_optout: The recipient has previously done an optout from the current publication or a total opt-out
not_sent_due_to_bounce: The recipient has bounced in a previous sendout for this lime-marketing site
not_sent_due_to_shared_block_list: The recipient is on the "shared block list". It means that they have previously bounced for another customer.

You can test the not_sent_due_to_shared_block_list functionality by adding the recipient [email protected] to your sendout.

How to Create a Content Block for the Object Content Integration¶

The content block is created using standard HTML. The object content data is inserted with Vue syntax. Read more about Vue here.

Required HTML-attributes:

data-editor-query-name: The name of the query defined in the Lime Admin config.
data-editor-contentblock-editor-type: Must be set to BizWizard.CMS.Editors.LimeCRM.
data-editor-get-content-as-list: This determines if the data should be fetched as the first limeobject matching the lime-query filter or a list of all matching objects.

Example¶

The query for this contentblock looks like this:

  {
      "limetype": "deal",
      "responseFormat": {
          "object": {
              "_id": {
                  "_alias": "dealid"
              },
              "name": null,
              "value": null,
              "coworker":{
                  "_id": {
                      "_alias": "coworkerid"
                  },
                  "firstname": null,
                  "lastname": null
              },
              "company":{
                  "name": null
              }
              }
      },
      "filter": {
          "op": "=",
          "key": "coworker._id",
          "exp": "{0}"
      }
  }

And the HTML for the contentblock:

<table data-editor-contentblock align="center" border="0" cellspacing="0" cellpadding="0">
  <tr>
    <td data-editor-contentblock-editor data-editor-contentblock-editor-type="BizWizard.CMS.Editors.LimeCRM" data-editor-query-name="deals_query" data-editor-get-content-as-list="true" data-editor-contentblock-editor-name="LimeCRM Content">
      <table align="center" border="0" cellspacing="0" cellpadding="0" width="100%">
        <tr>
          <td align="center">
            <table style="margin: 10px 40px;">
              <tr>
                <td v-for="m in objectContent" data-editor-contentblock-editor data-editor-contentblock-editor-name="Deal" data-editor-contentblock-editor-type="BizWizard.CMS.Editors.Text">
                  <table style="padding:10px; margin: 0px 5px; background-color:#FFFFFF">
                    <tr>
                      <td>
                        <table style="line-height:1.3em; padding-top:10px">
                          <tr>
                            <td ><span id="content-body"><strong style="color: #00b3a7">{{m.name}}</strong></span></td>
                          </tr>
                          <tr>
                            <td><span id="content-body">{{m.value}}</span></td>
                          </tr>
                          <tr>
                            <td>
                              <span id="content-body">{{m.coworker.firstame}} {{m.coworker.lastname}}</span>
                            </td>
                          </tr>
                          <tr>
                            <td>
                              <span id="content-body">{{m.company.name}}</span>
                            </td>
                          </tr>
                        </table>
                      </td>
                    </tr>
                  </table>
                </td>
              </tr>
            </table>
          </td>
        </tr>
      </table>
    </td>
  </tr>
</table>

To insert the data you can use the Vue viewmodel objectContent. This will either be an object or a list of objects depending on the value of the data-editor-get-content-as-list attribute.

Use dot-notation on the viewmodel to access data from a single object result:

<span>{{objectContent.name}}</span>

Use vue syntax on the table data tag to loop through list results:

<td v-for="m in objectContent"></td>

Access data from iterated objects through dot-notation on the alias ('m'):

<span>{{m.name}}</span>

Remember that Vue can not have properties starting with '_'. Any underscores will be cleaned automatically from the object content model if you forget to create an alias in your lime-query.

To insert an image to your contentblock you will need to access the image through an url as a property on the limeobject. Then you use the Vue method v-bind:src to display the image:

<td align="center"><img v-bind:src="m.imageurl" alt="Image of coworker" width="150"></td>

Content Block Structure¶

A breakdown of the required structure, based on the example block above.

The Container¶

<table data-editor-contentblock align="center" border="0" cellspacing="0" cellpadding="0">
.
.
.

- data-editor-contentblock: Used to identify the table which contains the content block.

The Editable Data¶

<td data-editor-contentblock-editor data-editor-contentblock-editor-type="BizWizard.CMS.Editors.LimeCRM" data-editor-query-name="deals_query" data-editor-get-content-as-list="true" data-editor-contentblock-editor-name="LimeCRM Content">
    .
    .
    .
    <td v-for="m in objectContent" data-editor-contentblock-editor data-editor-contentblock-editor-name="Deal" data-editor-contentblock-editor-type="BizWizard.CMS.Editors.Text">

- data-editor-contentblock-editor: Identifies a section which should be editable in the right hand menu.

The example above contains two instances of this attribute. The outermost, in combination with the `data-editor-contentblock-editor-type="BizWizard.CMS.Editors.LimeCRM"`attribute, adds the main editor in which you execute your search.

The inner adds a text editor for each company-table created from the search results in order to enable editing of the individual table data blocks.

data-editor-query-name: The name of the query defined in the Lime Admin config.
data-editor-get-content-as-list: Determines if the result should be fetched as a list or as a single object.
data-editor-contentblock-editor-name: Sets the name of the content block editor.

Required structure¶

This is the standard structure that the integration expects and needs to function properly, however every table and field name can be configured in the lime-admin config.

In order to get the consent flow working you must have the relations to the campaign and person tables. If you do not want to use consents you can hide the consenttype and consent table, but they must still exist in your database. You must also have at least one consent type created.

Mailing¶

Field name	Required	Suggested local name(en/sv)	Field type	Description
subject	x	Subject/Titel	Text field	The subject from the mailing (1024 characters)
campaign	x	Marketing activity/Marknadsaktivitet	relation (1:n campaign-mailing)	Relation to the campaign, a campaign can have many mailings
statisticlink	x	Statistics link/Statistiklänk	Link field	Hidden field used to hold statistic link from Lime Marketing (1024 characters)
sendoutlink	x	Sendout link/Utskickslänk	Link field	Hidden field used to hold send out link from Lime Marketing, i.e the actual layout of the mail sent (1024 characters)
htmlstatisticlink	x	Statistics/Statistik	HTML-tab	SQL-expression: mailing.[statisticlink]. Displays the content of the statistic link
htmlsendoutlink	x	Sendout/Utskick	HTML-tab	SQL-expression: mailing.[sendoutlink]. Displays the content of the send out link
mailingid	x	Newsletter ID	Text field	The mailing id from Lime Marketing, should be hidden
senddate	x	Sent/Skickat	Date	The date when the mailing was sent
recipient	x	Mailing recipient/Utskicksmottagare	relation (1:n mailing-recipient)	Relation tab to the recipients, a mailing can have many recipients
linkclick		Relation(1:n mailing-linkclick)	Relation to linkclick, a mailing can have many linkclicks (Only add if using linkclick)
emailopening		Relation(1:n mailing-emailopening)	Relation to emailopening, a mailing can have many emailopenings (Only add if using emailopening)

Recipient¶

Field name	Required	Suggested local name(en/sv)	Field type	Description
person	x	Person	relation: (1:n person-recipient)	Relation to the person, a person can have many recipients
mailing	x	Mailing/E-postutskick	relation: (1:n mailing-recipient)	Relation to the mailing, a mailing can have many recipients
sendoutstatus	x	Sendout status/Utskicksstatus	Option list(sent, open, clicked, bounce, optout, not_sent_due_to_optout, not_sent_due_to_bounce, not_sent_due_to_shared_block_list)	Used to set status for the mailing. must contain correct option keys

Marketing activity(Campaign)¶

Field name	Required	Field type	Description
name	x	Text field	Name of the marketing activity
type		Option list	Used to filter out the kind of campaigns to see in Newsletter
campaignstatus		Option list	Used to filter out the status of campaign to see in Newsletter
participant	x	Relation(1:n campaign-participant)	The participants that will get the sendout
mailing	x	Relation(1:n campaign-mailing)	The mailing sent in Newsletter
consenttype		Relation(n:1 campaign-consenttype)	Send mail to persons with a consent of this type

Person¶

Field name	Required	Field type	Description
email	x	Link field	Email to person IMPORTANT
totaloptout		Checkbox	Shows if the person has done an optout in Newsletter, if set the person will not be included when importing campaign participants
emailhardbounce		Checkbox	Shows if the person has a hard bounce in Newsletter
recipient	x	Relation(1:n person-recipient)	Relation to recipient, a person can have many recipients
consent		Relation(1:n person-consent)	Relation to consent, a person can have many consents.
participant	x	Relation(1:n person-participant)	Relation to participant, a person can have many participants
linkclick		Relation(1:n person-linkclick)	Relation to linkclick, a person can have many linkclicks (Only add if using linkclick)
emailopening		Relation(1:n person-emailopening)	Relation to emailopening, a person can have many emailopenings (Only add if using emailopening)

Participant¶

Field name	Required	Field type	Description
person	x	Relation(1:n person-participant)	Relation to person(Can be changed to something else e.g Company)
campaign	x	Relation(1:n campaign-participant)	Relation to campaign

Consenttype (Optional)¶

Field name	Required	Field type	Description
title	x	Text field	Name of the consenttype
consent	x	Relation(1:n consenttype-consent)	Relation to consent
campaign	x	Relation(1:n consenttype-campaign)	Relation to campaign

Field name	Required	Field type	Description
person	x	Relation(n:1 consent-person)	Relation to person
consenttype	x	Relation(n:1 consent-consenttype)	Relation to consenttype
approved	x	checkbox	Approved consent equals a Newsletter opt-in
source	x	Option list	Where did the consent come from

Linkclick (Optional)¶

Field name	Required	Suggested local name(en/sv)	Field type	Description
person	x	Person/Person	Relation(n:1 linkclick-person)	Relation to person (or other table connected to recipients)
mailing	x	Mailing/Utskick	Relation(n:1 linkclick-mailing)	Relation to mailing
linkname	x	Name/Namn	string	Name of the link (1024 characters)
linkurl	x	URL/URL	string	the URL of the link (1024 characters)
linkvalue	x	Value/Värde	integer	the value of the link
linkclicktime	x	Click time/Tid för länkklick	time	the timestamp of the link click
linkcategoryid	x		integer	id of the link category (Should be hidden)
linkcategoryname	x	Category/Kategori	string	name of the link category (1024 characters)

Emailopening (Optional)¶

Field name	Required	Suggested local name(en/sv)	Field type	Description
person	x	Person/Person	Relation(n:1 emailopening-person)	Relation to person (or other table connected to recipients)
mailing	x	Mailing/Utskick	Relation(n:1 emailopening-mailing)	Relation to person (or other table connected to recipients)
emailopeningtime	x	Opening time/Tid för öppning	time	the timestamp of the emailopening

Endpoints¶

These are the endpoints that are used by the lime-newsletter integration.

The requests are made to the Lime solution https://\<DOMAIN>/\<APP-NAME>

Method	URL
GET	newsletter/v2/campaigns/
GET	newsletter/v2/campaign/{int:idcampaign}/participants/
GET	newsletter/v2/campaign/{int:idcampaign}/
POST	newsletter/v2/mailing/
GET	newsletter/v2/participantfields/
GET	newsletter/v2/participants/{int:idcampaign}/
GET	newsletter/v2/participants/{int:idcampaign>/{int:idconsenttype}/
GET	newsletter/v2/recipients/{int:idmailing}/
GET	newsletter/v2/publicationmapping/
GET	newsletter/v2/verify/
POST	newsletter/v2/webhook/
GET	newsletter/v2/objectcontent/{string:queryname}/
GET	newsletter/v2/capabilities/

Web components¶

lime-newsletter contains the IFramed Content component that makes it possible to display Lime Marketing content in an IFrame. The component can be configured to display any content.

Example use case: View the url of the statistics link property on the mailing card in a custom tab

webcomponent

Add the component by adding lwc-lime-newsletter-iframed-content to your limetype under Views -> Custom Tabs

Properties:¶

urlPropertyName: The property on the limetype which contains the url of the content to display in the component.

customHeight: A custom height value (e.g. "1637px", "100%"). If no custom height is defined the component defaults to 100%.

customWidth: A custom width value (e.g. "950px", "100%"). If no custom width is defined the content defaults to 100%.

customBackgroundColor: A custom background color for the iFrame container. If no custom color is defined the color defaults to #FFFFF (white).

customScrolling: Should scrolling be enabled in the iFrame? Default to "auto" but can be set to "yes" or "no".

exampleconfig
